Leading Global Solar Energy Storage Manufactuer, Making Green Power Anywhere Anytime.
★ Automotive Grade LiFePO4 cells that meet UL /CE certification standards, up to 5000 cycles.
★ Maximum 100A input current, adaptation to high power components.
★ Our equalization-enabled BMS can regulate cell consistency and safeguard against short circuits and over-current, thereby enhancing battery safety and durability.
★ Simultaneous connection to utility grid/generator and PV
★ Integrated inverter & battery, All-In-One design for installation, greatly reducing investment and maintenance costs.
★ Stylish and stackable design, for a variety of home use and outdoor application scenarios.
★ You can use 4 batteries in parallel at the same time, and can easily expand to a maximum of 20.48kwh for your use.
★ With remote WIFI control, Use enhanced security features and multiple safety protection functions from hardware to software
TYPE |
POWER CUBE HR5K-100A |
Battery | |
Battery Type | LiFePO4@GF |
Nominal Capacity | 100Ah |
Rated Battery Voltage | 51.2V |
Operating Voltage Range | 40~58.4V |
Max Charging Current | 100A |
Max Stack Quantity | 4 Stack |
Operating Temperature Range | Charge:0~60℃&32~140°F, Discharge:-20~60℃&-4~140°F |
Operating RH | 0-95% RH |
Working Altitude | <3000m |
Assembly Method | Stack |
Net Weight | ≈51kg |
Size | 841*640*449mm |
PV Input | |
Num.of MPPT Trackers | 1 |
Max.PV Array Power | 5200W |
Max.Input Current | 18A |
Max.Voltage of Open Circuit | 500Vdc |
MPPT Voltage Range | 120~450Vdc |
MPPT Tracking Efficiency | 99.9% |
Inverter Output | |
Rated Output Power | 5,000W |
Max.Peak Power | 10,000W |
Rated Output Voltage | 120Vac(Single-Phase L+N+PE) |
Max. Battery Inverter Efficiency | >90% |
Load Capacity of Motors | 4HP |
Rated AC Frequency | 50/60Hz |
Wave Form | Pure sine wave |
The Green Power Stackable Energy Storage System, featuring a 5KW Inverter and a robust 10KWh battery, presents a highly portable solution for reliable home and outdoor energy storage. Boasting an impressive 10KWh capacity, this system caters to scenarios where conventional wall outlet access is scarce or nonexistent, making it an ideal companion for various outdoor adventures.
Characterized by its innovative stackable architecture, the system seamlessly combines an inverter and an energy storage battery, resulting in a streamlined appearance and simplified installation process. Its modular design allows for effortless scalability, accommodating up to four additional batteries for a maximum combined capacity of 20kWh. With a rated output power of 10000W, the system capably supports a wide array of everyday household appliances, including televisions, refrigerators, LED lighting, water heaters, cameras, computers, fans, routers, smartphones, and many others.
Functioning as a comprehensive energy management hub, the Green Power Stackable Energy Storage System operates seamlessly and safely. The inverter efficiently receives and processes electricity from diverse sources such as solar photovoltaic panels and the main electrical grid. It then adeptly transforms the incoming DC power into a stable AC supply, catering to the demands of your household loads. Concurrently, any surplus energy is diligently stored within the integrated battery, empowering you to embrace an autonomous, off-grid lifestyle with ease and confidence.
COMMERCIAL TERMS | |
Sample Time |
35 Days |
Lead Time |
55 Days |
Payment |
30-50% Deposit in Advanced, Rest% Made Before Shipment |
For home battery backup products equipped a large number of internal battery cells, we work with clients to inspect each node on-site after the batteries are completed.
GreenPower places a strong emphasis on product design and engineering for mass production. Colleagues in our Quality Engineering Department have extensive experience in large-scale quality production.
GreenPower has complete testing equipment to ensure high-standard testing and inspection support for products during the sample and mass production stages.
Given the unique safety requirements of lithium-ion products, GreenPower insist on testing each product's performance after it has been left stationary.
In the event of occasional delays in customer delivery times, GreenPower’s warehouse provides free storage for completed orders for a certain period.
With our extensive experience in cross-border logistics, we are familiar with China's import and export regulatory agencies and can assist clients with customs clearance and other related processes.
